This is the playlist of my step by step tutorials for Canon portable PIXMA series printers.
In this video (part2) I am setting up and connecting PIXMA TR150:
00:00 Introduction
00:40 Preparing the printer
01:10 Printer Setup (printer head and inks)
04:00 Wireless Setup
06:00 Print with Canon PRINT App
07:00 More Connectivity with App
08:00 More about PIXMA portable printers
#PIXMA
#TR150
#Setup
See more printer videos on my channel: In this video:
PIXMA TR150 specs site:
see official site for discmlaimers
Print
Print Head / Ink
Type Permanent
Number of Nozzles Total 1,856 nozzles
Ink Cartridges PGI-35, CLI-36
Maximum Printing Resolution
4800 (horizontal)*1 x 1200 (vertical) dpi
Print Speed Based on ISO/IEC 24734
Document (ESAT/Simplex)
Approx. 9.0 ipm (black) / 5.5 ipm (colour)
Photo (4 x 6″) (PP-201/Borderless) 53 sec
Printable Width Up to 203.2 mm (8″)
Borderless: Up to 216 mm (8.5″)
Printable Area
Borderless Printing
Top/Bottom/Left/Right margin: each 0 mm
Bordered Printing
#10 Envelope/DL Envelope:
Top margin: 3 mm, Bottom margin: 12.7 mm,
Left/Right margin: each 3.4 mm
Square (127 mm):
Top/Bottom/Right/Left margin: each 6 mm
Square (89 mm/4 inch):
Top/Bottom/Right/Left margin: each 5 mm
Letter/Legal:
Top margin: 3 mm, Bottom margin: 5 mm,
Left margin: 6.4 mm, Right margin: 6.3 mm
Others:
Top margin: 3 mm, Bottom margin: 5 mm,
Left margin: 3.4 mm, Right margin: 6.3 mm
Support Media Rear Tray
Plain Paper
Glossy Photo Paper (GP-508)
High Resolution Paper (HR-101N)
Matte Photo Paper (MP-101)
Double-Sided Matte Paper (MP-101D)
Photo Paper Plus Glossy II (PP-201)
Photo Paper Plus Glossy II (PP-208)
Photo Stickers (PS-108/PS-208/PS-808)
Removable Photo Stickers (PS-308R)
Magnetic Photo Paper (PS-508)
Envelope
Paper Size Rear Tray
A4, A5, B5, LTR, LGL, Envelopes (DL, COM10), Square (5 x 5″, 3.5 x 3.5″), Card Size (91 x 55 mm), 4 x 6″, 5 x 7″, 7 x 10″, 8 x 10″
[Custom size]
Width 55 – 215.9 mm, length 89 – 676 mm
F4 is possible via custom size settings.
Paper Size (Borderless) A4, Letter, 4 x 6″, 5 x 7″, 7 x 10″, 8 x 10″,
Card Size (91 x 55 mm), Square (5 x 5″, 3.5 x 3.5″)
Paper Handling (Maximum Number) Rear Tray
Plain Paper (A4/Letter) = 50
Plain Paper: 64 – 105 g/m²
Canon speciality paper: max paper weight: approx. 275 g/m²
(Photo Paper Plus Glossy II PP-201)
Ink End Sensor Dot count
Print Head Alignment Auto/Manual
Network Protocol
SNMP, HTTP, TCP/IP (IPv4/IPv6)
Wireless LAN
Network Type IEEE802.11n/g/b/a
Frequency Band 2.4 GHz 5 GHz
Channel 2.4 GHz: 1 – 13, 5 GHz: W52, W53, W58
5 GHz connection will be disconnected during the Direct Wireless mode
Range
Indoor 50 m (depends on the transmission speed and conditions)
Security WEP64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES)
Direct Connection (Wireless LAN) Available
Printing Solutions
AirPrint
Windows 10 Mobile
Mopria (for Android)
Canon Print Service (for Android)
PIXMA Cloud Link (from smartphone/tablet)
Canon PRINT Inkjet/SELPHY (for iOS/for Android)
System Requirements
Windows 10 / 8.1 / 7 SP1
(operation can only be guaranteed on a PC with a pre-installed Windows 7 or later)
OS X 10.11.6, macOS 10.12 ~ 10.15
Chrome OS
General Specifications
Operation Panel Display 1.44″/3.6 cm OLED Display (Monochrome)
Interface USB Type C Hi-Speed USB
PictBridge (Wireless LAN)
Operating Environment
Temperature 5 – 35°C
Humidity 10 – 90% RH (no dew condensation)
Recommended Environment
Temperature 15 – 30°C
Humidity 10 – 80% RH (no dew condensation)
Storage Environment
Temperature 0 – 40°C
Humidity 5 – 95% RH (no dew condensation)
Quiet Mode Available
Acoustic Noise (PC Print) Plain Paper (A4, B/W) Approx. 40.5 dB(A)
Power AC 100-240 V, 50/60 Hz
Power Consumption
When off: Approx. 0.3 W
USB connection to PC Approx. 1.1 W
Standby (all ports connected, scanning lamp is off)
(EU only – for ErP Lot 26 regulation) Approx. 1.7 W
Time to enter Standby mode Approx. 3 min
(EU only – for ErP Lot 26 regulation)
Printing (USB connection to PC) Approx. 8 W
Environment Regulation RoHS (EU, China), WEEE (EU)
Duty Cycle Up to 500 pages/month
Dimension (WxDxH)
Without Battery Approx. 322 x 185 x 66 mm
With Battery Approx. 322 x 210 x 66 mm
Tray Extended Approx. 322 x 307 x 245 mm
Weight Approx. 2.1 kg or 2.3 kg With Battery
Page Yield Plain Paper (A4) (ISO/IEC 24712 test file)
PGI-35: 200
CLI-36: 260
Photo Paper PP-201, 4 x 6″ (ISO/IEC 29103 test file)
PGI-35: 7113 (used only while cleaning, not for photo print)
CLI-36: 102
Portable Kit (Optional) LK-72 Type Lithium-ion
Voltage Level DC 10.8 V; 2170 mAh
Charging Time (Approx.)
2hrs 20 min (AC adaptor)
5hrs (USB 1.5 A)
Remaining Indication LED 4 steps
Printable Pages 330 sheets
Printable Pages – 10 min charge with AC adaptor
36 sheets
Printable Pages – 5 min charge with USB 1.5A 4 sheets
source
